Ditch Witch FX60 Vacuum Excavator

• 60-hp (45kW) Cummins diesel engine
• Saddle-style tanks
• Length 6.22m
• Width 2.55m
• Height 2.52m
• Weight (dry) 5,094kg
• Weight (vac tank full, water tank full) 11,104kg
• Weight (Vac tank full, water tank empty) 9,580kg
• Weight (Water tank full, vac tank empty) 6,940kg
• Engine type: Cummins B3.3NA
• Fuel type: diesel
• Aspiration: natural
• Vacuum system Blower displacement: 25.5m3/min
• Maximum vacuum: 406mm HG
• Hose size (standard): 102mm
• Vacuum tank capacity: 4,543L
• Full opening rear door diameter: 1.58m
• Outlet valve size: 152mm
• Tank inlet valve size: 102mm
• Primary shutoff (ball type): 305mm
• Filter area: 9.3m3
• Water trap capacity: 30.3L
• Suction hose 4 in (2 sections): 15.2m
• Water system
• Water pump flow: 23.6L/min
• Water pump pressure (max) 241 bar
• Pump clutch: electric with antifreeze and auto declutch feature
• Hydraulic system
• 12V DC power unit
• Reservoir size: 57L
• Pressure: 172 bar
• Tank dump cylinders: 102mm
